UNION MORTICE LOCK 5 LEVER 76mm CASE DP
Stock Code:
UN Y2201 3.0 SC
Description
APPLICATION
For timber doors hinged on left or right
To suit doors up to 54mm thick
SPECIFICATION
Deadbolt locked or unlocked by key from either side
Latch bolt withdrawn by lever handle from either side
May be keyed alike with 2101 and 2401
Security box striking plate
Easily reversible latch bolt from outside of case
Case Size: 77.5mm (3")
Backset: 57mm
Case: Steel, red powder coat
Deadbolt: Brass, with hardened steel rollers
Latch Bolt: Brass, easily reversible
Follower: Brass, 8mm square
Supplied with 2 steel nickel plated keys
Key Blank Number: KB430
Keying: 600 standard differs (keys are not numbered for security purposes)
Available in SC and PL finishes
FINISH
SC - Satin Chrome finish
Rebate Kit: 2989
Stock Level:
In Stock
